Ultra Mini Size
Made of steel(SPCC) , this mini-ITX computer case is only 13.4" * 5.8" * 9.3", it is only takes up 11.6L space.
360 Degree Accessibility
Every panel and frame part can be dismantled to allow advanced disassembly and 360 degrees of access to work on components.
Dedicated GPU Support
Two slot GPUs are supported with a maximum length of 330mm and maximum width of 150mm.
01
Ultra Mini Size
Made of steel(SPCC) , this mini-ITX computer case is only 13.4" * 5.8" * 9.3", it is only takes up 11.6L space. Besides, this little case is flanked with five ventilated steel panels for unrestricted airflow.
02
360 Degree Accessibility
Every panel and frame part of this case can be dismantled to allow advanced disassembly and 360 degrees of access to work on components.
03
Mini-ITX Mother Board Support
Because the mini size design, this mini case only supports mini-ITX mother board with the size of 6.7" * 6.7".
04
Dedicated Graphics Support
This mini ITX computer case can support 2 slot dedicated graphics card with the size no more than 13" * 2.7" * 5.9" through PCIe4.0/3.0 extension cable.
05
Cooling
This mini ITX computer case can support CPU fan cooling or 120 /240 water cooling; when using the fan to cool the CPU, the height of the fan needs to be less than 2.8"; when using the 120-water cooling. the radiator needs to be less than 2.24" and there are also 2 top (12015) and 2 bottom(12025) system cooling fan available.
06
SFX/SFX-L PSU
This little ITX case can support SFX or SFX-L Power Supply which usually provide 1*24Pin Mother board power socket, 1*8Pin CPU power socket; 2*8(6+2) Pin graphics card socket; 6 SATA power socket and 3* 4Pin Power Socket.
07
Storage
This mini case can support 2 2.5" SSD or 1 3.5" HDD.
08
PCIe Cable
The dedicated graphics is connected to the ITX mother board through a PCIe extension cable ,the direction of the 2 connector is 180 degree and the length of the cable is around 7".
